6 Cores & 12 Threads
3.6 GHz Base Clock
4.2 GHz Max Boost Clock
Socket AM4
3 MB L2 & 32 MB L3 Cache
Dual-Channel DDR4-3200 Memory
Supports PCIe 4.0 x16
Wraith Stealth Cooler Included
AMD "Zen 3" Core Architecture
The fastest cores in the world for PC gamers.
AMD StoreMI Technology
A fast and easy way to expand and accelerate the storage in a desktop PC with an AMD Ryzenâ„¢ processor.
AMD Ryzenâ„¢ Master Utility
The Simple and Powerful Overclocking Utility for AMD Ryzenâ„¢ processors.
Platform : Desktop
Market Segment : Mainstream Desktop
Product Family : AMD Ryzenâ„¢ Processors
Product Line : AMD Ryzenâ„¢ 5 Desktop Processors
Consumer Use : Yes
Regional Availability : Global, China, NA, EMEA, APJ, LATAM
Former Codename : "Vermeer"
Architecture : "Zen 3"
# of CPU Cores : 6
Multithreading (SMT) : Yes
# of Threads : 12
Max. Boost Clock : Up to 4.4GHz
Base Clock : 3.5GHz
L1 Cache : 384KB
L2 Cache : 3MB
L3 Cache : 32MB
Default TDP : 65W
Processor Technology for CPU Cores : TSMC 7nm FinFET
Processor Technology for I/O Die: 12nm (Globalfoundries)
CPU Compute Die (CCD) Size : 74mm²
I/O Die (IOD) Size : 125mm²
Package Die Count : 2
Unlocked for Overclocking : Yes
CPU Socket : AM4
Socket Count : 1P
Supporting Chipsets : X570
CPU Boost Technology : Precision Boost 2
Instruction Set : x86-64
Supported Extensions : AES, AMD-V, AVX, AVX2, FMA3, MMX(+), SHA, SSE, SSE2, SSE3, SSE4.1, SSE4.2, SSE4A, SSSE3, x86-64
Thermal Solution (PIB) : AMD Wraith Stealth
Max. Operating Temperature (Tjmax) : 90°C
*OS Support : Windows 11 - 64-Bit Edition
Windows 10 - 64-Bit Edition
RHEL x86 64-Bit
Ubuntu x86 64-Bit
*Operating System (OS) support will vary by manufacturer.
Connectivity
USB Type-C® Support : Yes
Native USB 3.2 Gen 2 (10Gbps) Ports : 4
Native USB 3.2 Gen 1 (5Gbps) Ports : 0
Native USB 2.0 (480Mbps) Ports : 0
Native SATA Ports : 2
PCI Express® Version : PCIe 4.0
Native PCIe® Lanes (Total/Usable) : 24/20
Additional Usable PCIe Lanes from Motherboard : AMD X570 16x Gen 4
AMD X470 2x Gen 3
AMD X470 8x Gen 2
NVMe Support : Boot, RAID0, RAID1, RAID10
System Memory Type : DDR4
Memory Channels : 2
Max. Memory : 128GB
System Memory Subtype : UDIMM
System Memory Specification : Up to 3200MHz
Max Memory Speed : 2x1R DDR4-3200
2x2R DDR4-3200
4x1R DDR4-2933
4x2R DDR4-2667
Graphics Capabilities
Product IDs
Product ID Boxed : 100-100000927BOX
Product ID Tray : 100-000000927
Key Features
Supported Technologies :
AMD StoreMI Technology
AMD "Zen 3" Core Architecture
AMD Ryzenâ„¢ VR-Ready Premium
