16 Cores & 32 Threads
4.5 GHz Base Clock
5.7 GHz Max Boost Clock
Socket AM5
16MB L2 & 64MB L3 Cache
Integrated AMD Radeon Graphics
DDR5-6400 Memory
Unlocked Processor
Zen 4 Architecture
Level up your gaming and creator experience
AMD Ryzenâ„¢ 9 7950X processor can do it all with hyper fast single-core and multi-core performance for the most demanding gamers and creators.
The world’s most advanced PC processor1
When your PC has an AMD Ryzen™ 9 7950X processor, the world’s most advanced PC processor1 for gamers, you can focus on what really matters: being victorious on the digital battlefield.
The latest technologies from AMD
AMD Ryzen™ 9 7950X processor is built to help you beat the clock with time-saving connectivity like PCIe® 5.0, 32 processing threads, and dedicated video accelerators2.
The future of Ryzen processors
Power. Performance. Possibility. AMD Socket AM5 motherboards deliver new features for gamers, from the speed of DDR5 memory and AMD EXPO™ technology3 to the increased bandwidth with PCIe® 5.0.Platform : Desktop
Market Segment : Enthusiast Desktop
Product Family : AMD Ryzenâ„¢ Processors
Product Line : AMD Ryzenâ„¢ 9 Desktop Processors
AMD PRO Technologies : No
Consumer Use : Yes
Regional Availability : Global
Former Codename : "Raphael AM5"
Architecture : "Zen 4"
# of CPU Cores : 16
Multithreading (SMT) : Yes
# of Threads : 32
Max. Boost Clock : Up to 5.7GHz
Base Clock : 4.5GHz
L1 Cache : 1MB
L2 Cache : 16MB
L3 Cache : 64MB
Default TDP : 170W
Processor Technology for CPU Cores : TSMC 5nm FinFET
Processor Technology for I/O Die : TSMC 6nm FinFET CPU Compute Die (CCD) Size : 71mm²
I/O Die (IOD) Size : 122mm²
Package Die Count : 3
Unlocked for Overclocking : Yes
AMD EXPOâ„¢ Memory Overclocking Technology : Yes
Precision Boost Overdrive : Yes
Curve Optimizer Voltage Offsets : Yes
AMD Ryzenâ„¢ Master Support : Yes
CPU Socket : AM5
Supporting Chipsets
CPU Boost Technology : Precision Boost 2
Instruction Set : x86-64
Supported Extensions : AES, AMD-V, AVX, AVX2, AVX512, FMA3, MMX(+), SHA, SSE, SSE2, SSE3, SSE4.1, SSE4.2, SSE4A, SSSE3, x86-64
Thermal Solution (PIB) : Not included
Max. Operating Temperature (Tjmax) : 95°C
*OS Support
Windows 11 - 64-Bit Edition
Windows 10 - 64-Bit Edition
RHEL x86 64-Bit
Ubuntu x86 64-Bit
*Operating System (OS) support will vary by manufacturer.
Connectivity
USB Type-C® Support : Yes
Native USB 3.2 Gen 2 (10Gbps) Ports : 4
Native USB 3.2 Gen 1 (5Gbps) Ports : 0
Native USB 2.0 (480Mbps) Ports : 1
Native SATA Ports : 0
Native PCIe® Lanes (Total/Usable) : 28/24
Additional Usable PCIe Lanes from Motherboard : AMD X670E 12x Gen4
AMD X670 12x Gen4
AMD B650E 8x Gen4
AMD B650 8x Gen4
NVMe Support : Boot, RAID0, RAID1, RAID10
Memory Channels : 2
Max. Memory : 128GB
System Memory Subtype : UDIMM
Max Memory Speed : 1x1R 5200 MT/s
1x2R 5200 MT/s
2x1R 3600 MT/s
2x2R 3600 MT/s
Graphics Capabilities
Integrated Graphics : Yes
Graphics Model : AMD Radeonâ„¢ Graphics
Graphics Core Count : 2
Graphics Frequency : 2200 MHz
GPU Base : 400 MHz
USB Type-C® DisplayPort™ Alternate Mode : Yes
