POWER FOR PERFORMANCE : Able to support high-performance graphics cards including the NVIDIA GeForce RTX 40 Series and AMD Radeon RX 6000 Series.
SPACE-SAVING SIZE : Compact form factor frees up room for cable management and airflow, and works well in smaller cases where space is limited.
SILENT OPERATION : The 135mm PWM fan with a fluid dynamic bearing runs quietly, even at high loads. Zero Fan Mode shuts it off for total silence when under 50% load.
HIGH-QUALITY COMPONENTS : Built with only Japanese 105°C-rated capacitors for the highest standard in performance, reliability, and longevity.
This PSU delivers 1000 watts of clean, stable power and is ideal for gaming and workstation PCs that have multiple GPUs and high-performance CPUs. The C1000 supports the latest GPUs, including up to an NVIDIA RTX 3090 and AMD GPUs up to the 6900 XT.
Output Connectors
24-pin ATX power:1
4+4-pin CPU power:2
6+2-pin PCIe power:6
SATA power:6
Peripherals:6
Cable Specs
24-pin ATX power:600 mm, Nylon sleeving
4+4-pin CPU power:700 mm, Nylon sleeving
6+2-pin PCIe power:650 + 150 mm, Nylon sleeving
SATA power:500 + 150 mm
Peripherals:500 + 150 mm
AC Input Rating
100 - 240Vac:13A-6.5A 50Hz-60Hz
DC Output Rating
+3.3V and +5V:22A (120W)
+12V:83.5A (1002W)
-12V:0.3A (3.6W)
5Vsb:3A (15W)
Total:1000W
Operation
PF Correction:Active @0.96
MTBF:100,000 hours
Temperature:0 - 50 °C (derating from 100% to 80% from 40 °C to 50 °C)
Energy Efficiency
Rating:80 Plus Gold
20% loading:87% @115Vac
50% loading:90.5% @115Vac
100% loading:87.5% @115Vac
Fan Specs
Dimensions:135 x 135 x 25 mm
Speed:0-2300 ± 10% RPM
Airflow:93.02 CFM (Tpy.)
Noise:44.5 dBA max
Bearing:Fluid Dynamic Bearing (FDB)
General
Dimensions:150 x 150 x 86mm
Material(s):Steel, PCB and Plastic
Compliance Standard:ATX12V v2.52 / EPS12V v2.92
Regulation & Certification:cTUV-SUDus / CUL (UL60950/62368-1) / TUV / (EN60950/62368-1) / CB/ (IEC 950/62368-1) / CCC / CEC /BSMI / RCM / EAC / CE / LVD / UKCA
Model Number : PA-0G1BB
Inside the Box
C1000 Gold : 1
24-Pin ATX Power Cable : 1
4+4-Pin CPU Power Cables : 2
6+2-pin PCIe Power Cable : 3
SATA Cables : 2
Peripherals Cables : 2
6-32 Screws : 4
